Keypad

TE 501

Keypad

  • Keypad unit with 50 keys and 50 LEDs
  • 1x CAN with 2 connectors
  • 4 external switch elements can be added
  • Customer-specific foil and button allocation as desired
  • IP20 protection

Performance Data

Interfaces

12-pin connector for 4 x 3 switching elements

2-pin power connector

1x CAN with 2 connectors

Control Elements

50x function keys

4x switch recesses

Supply voltage

+24 V DC (+18-30 V DC)

Mechanical Features

Dimensions

320 x 260 x 46.7 mm (W x H x D)

Material

housing: Aluminum

front plate: aluminum

Protection type

IP20

Article Number/Certification

Article number

12-210-501

pdf | 127 KB
Product sheet TE 501
pdf | 243 KB
Documentation TE 501
zip | 1 MB
STEP File TE 501
