CPU Unit

CP 841

CPU Unit

  • High-performance CPU unit (up to 64 local I/O modules)
  • Intel® Atom x6413E quad-core processor
  • OPC UA communication
  • 2x Ethernet, 2x VARAN Out (Manager), 1x CAN, 2x USB 2.0 type A, 1x USB 3.2 type C (only host), 1x S-DVI



A real-time clock and zero-voltage proof RAM space with battery buffering are available.



For the S-DIAS system, EPLAN-Makros are available for simple integration into the control cabinet.





Performance Data

Processor

1.5 GHz Intel Atom x6413E

Processor core

4

Internal program and data memory

4 GB

Internal remnant data memory

1-Mbyte

Internal storage device

128-Gbyte M.2 SATA SSD

Interfaces

2x Ethernet

2x VARAN-Out Manager

1x CAN

2x USB 2.0 type A

1x USB 3.2 type C (only host)

1x S-DVI

1x S-DIAS

Supply voltage

+24 V DC ±20 %

Mechanical Features

Dimensions

60 x 110 x 193.5 mm (W x H x D)

Weight

1.35

Protection type

IP20

Article Number/Certification

Article number

20-004-841

Standardization/­certification

designed according to UL

CR2032-2 - Replacement battery

  • Rated voltage 3 V DC
  • Rated power 235 mAh
  • Strap (one-sided)
